Condominium Security Control Room: What Malaysian JMBs Need.

What is a condominium’s security control room for?

Most Kuala Lumpur high-rises do not have a room. They have a counter at the guardhouse, screens above it and a recorder underneath. That is still a security control room in the only sense a committee needs, the place where every layer of an Extra Low Voltage system surfaces at once: the cameras’ recorder, the access controller, the intercom head end and the network joining them.

It is where a split system becomes visible: the working argument for every layer, one contractor. So the question is not how many screens, but who can reach that equipment, who answers for it, and what the building can produce on request.

Those are committee questions, not guard-company questions. In a judgment dated 18 August 2025 the Shah Alam High Court held that a condominium management could not be liable for burglaries inside private units, because the Strata Management Act placed no legal duty on management to provide security; the court also found it had discharged its responsibility by appointing a security services company. Everything above that floor is what a building specified for itself: the reasoning behind the four layers a fault can live in.

Where should the recorder and the controllers physically be?

In a secure room; or where that is not practicable, a locked cabinet. Published United Kingdom police guidance for licensed premises is blunt: “The monitor and recording equipment should be located in a secure room. Where this is not practicable, the recording equipment must be stored in a secure cabinet to prevent unauthorised access, tampering, or removal of images.”

That is a yardstick a committee can hold a tender to, not a rule any Malaysian building must meet. The same document treats the integrity of images taken off a recorder as vital and says they “must be protected at the earliest opportunity to reduce opportunities for challenges in Court”. A recorder in an open cupboard behind a shift-staffed counter is not protected, and nobody can say later who stood in front of it.

Siting is a maintenance question too. A recorder of this class, the Panasonic WJ-NX1002E for example, displays on its maintenance page how far back the images on its disks go, and nobody reads that off a machine they cannot reach. Where it sits also decides riser routes, cooling, which circuit it runs on and whether it sits behind a backup supply: where a diagnosis starts when a recorder stops recording.

Who answers for the system, and who is licensed?

Two questions, only one of them regulated. Guards work for agencies licensed under the Private Agencies Act 1971, which the Dewan Rakyat voted to amend for the first time on 9 October 2025, passing the Private Agencies (Amendment) Bill 2025. The Deputy Home Minister told the House in October 2025 that 118,196 unarmed security guards were registered nationwide. Proving their rounds is a separate record again.

The equipment is not regulated that way: no licence attaches to a recorder, so the building names its own people. The UK guidance names two roles worth copying into a contract: a trained person responsible for “the general administration, operation, maintenance and supervision of the system”, and an identified “person responsible for the system and daily checking”. Section 90A(2) of the Evidence Act 1950 adds a third reason: a computer’s ordinary-use output can be proved by a certificate signed by the person responsible for the management of its operation, and a building with nobody in that role has nobody to sign. How footage holds up with the police or in court is set out already.

The machine keeps its own account: a recorder of this class carries user authentication, registered administrators, operation levels and an access log of who reached it. Those credentials appear on no asset list and do not transfer by themselves, so a building that cannot name the holder has not really taken the system over, and an incoming committee should ask for them among the things a JMB inherits at handover.

What must the room do on the day something happens?

Not watch. Produce. The UK guidance asks for a competent person on the premises at all operating times “capable of replay and export of recordings quickly onto a removable storage medium”; that pictures “be exported in the native file format at the same quality that they were stored on the system”; and that the master copy “will be available at the time on request of an investigating officer”.

Every line of it is set long before it is needed; who may receive the file is a separate written policy: what a release policy should say. The police report that starts an investigating officer’s request need not be made locally: the Royal Malaysia Police state that a report under section 107 of the Criminal Procedure Code may be lodged at any police station, even where the incident happened elsewhere.

What can a wall of monitors honestly deliver?

Less than most committees expect, and that is no criticism of the guards. Watching catches what is happening now; retrieval is what a building is judged on afterwards, and it turns on two numbers, not the number of screens: pixels per metre, and days of retention.

The first is picture detail at the scene. The UK guidance, drawing on advice from the Home Office Centre for Applied Science and Technology, sets three standards: Identify at 250 pixels per metre, Recognise at 125 and Observe at 62.5. A camera specified to Observe shows distinctive clothing and distinguishes individuals, but will not identify a face beyond reasonable doubt, on any size of monitor. That is identification versus observation, and it belongs in the operational levels of a scope of works, camera by camera.

The second is retention, a setting, not a property of the equipment. Systems are often set to over-record after a set period; the same guidance asks for 31 days of images before that happens. Your figure is whatever the disks and settings allow; the retention line in a scope of works is where it stops being an accident. That argues for cameras that work in the dark: 77.6 per cent of Malaysia’s house break-in and theft cases in 2024 happened at night, in a year when those cases fell 1.8 per cent even as property crime overall rose 12.4 per cent to 47,188.

What should a committee settle before anyone prices this?

Five things, in writing, before a quotation is sought: where the recording equipment will sit, who holds the key and whether it has a backup supply; who the named person responsible for the system and its daily checking is; who holds administrator access; what the picture standard is, camera by camera; and how many days of recording the building is buying.

None of those is a product decision, and that is the point. The 2025 judgment held that the level of security depended on what residents agreed to and what they were willing to pay, and that “The onus is on the plaintiff to prove breach of responsibility based on the applicable regulations and laws”. A specification the committee can show is its own protection, and it is what should reach the meeting that approves the money, rather than three prices for different things. Record what the building already has first, the way proof of condition works in a maintenance contract.

Occhio Tec is an Extra Low Voltage contractor established in 2012, designing, installing and maintaining CCTV, access control, video intercom and structured networking for condominiums in Mont Kiara, Bangsar and KLCC, including systems another contractor installed. MicroEngine appointed it an Authorised System Installer in 2014; Panasonic Malaysia an Authorised Strategic Partner for ELV works in 2015. What a monitoring position can do is not readable off a drawing: request a site survey, or message +60 11-6494 4931.
